Stadium for Bath
Architectural visualisations for a proposed 18,000-seat civic and community stadium in Bath
Client: Bath Rugby
Architect: Kay Elliott (design team)
Location: Bath, Somerset
Project Type: Public & Community / Sports & Civic Regeneration
Services: Architectural Visualisation, Planning CGI, Public Consultation Visuals, Design Development Imagery
Capacity: 18,000-seat stadium (proposed)
Context: UNESCO World Heritage City / Riverside regeneration site
JJV produced a series of architectural visualisations for the proposed Stadium for Bath Rugby, a major civic and community-led redevelopment within the heart of Bath’s UNESCO World Heritage city.
Working with the project design team, the imagery was developed to communicate the scale, ambition and sensitivity of the 18,000-seat stadium proposal within one of the UK’s most historically significant urban settings. The visualisations supported planning discussions, design development and public consultation throughout the evolution of the scheme.
The spiritual home of Bath Rugby for over 125 years
Community Features
18,000 capacity stadium with significantly enhanced accessibility provisions
Contemporary and sensitive design
New hybrid pitch increasing community and amateur use
Regenerated riverside including the new Spring Gardens Walk
Retention of mature trees, as well as further landscaping and bio-diversity measures
A host of sustainability measures to support a target of net zero operational carbon
Riverside café/restaurant, Club shop and museum for non-matchday use
Located on a highly sensitive riverside site, the proposed stadium forms part of a wider regeneration strategy for Bath’s Recreation Ground, balancing modern sporting infrastructure with the preservation of key historic views and public realm.
The visualisations focused on demonstrating how the stadium sits within its wider urban context, helping stakeholders understand the relationship between the new structure, the River Avon and the surrounding cityscape.
The latest re-design is a direct result of consultations and public feedback from the initial design back in 2023. The key benefits of these new designs include:
A new curved roof form which reduces the heights, resulting in increased views of the city and surrounding hills
Enhanced landscaping to the river
Redesign of East and West Stand facades
Re-engineered and enhanced seating bowl
To see the CGI’s we produced for the first design, head to the bottom of this page.
Architectural Features
The project represents a significant example of civic and sporting architecture, where design quality, heritage sensitivity and community value must all be carefully balanced. The visualisations helped bridge the gap between concept and understanding, supporting a clearer dialogue around one of Bath’s most important contemporary developments.
Match Day Experience
Non-Match Day Experience
A key aspect of the visualisation work was supporting public engagement and planning communication. The CGI helped translate complex architectural proposals into clear and accessible imagery for both technical stakeholders and the wider public.
By presenting the scheme within its real-world context, the visuals played an important role in communicating design intent, scale and impact across consultation stages.
“We are absolutely delighted to have submitted our proposals. This is the culmination of many years of collaboration, listening and refining, which we now believe delivers the world-class facility that Bath Rugby and the wider city deserves.”
— Tarquin McDonald, CEO of Bath Rugby
2023 | INITIAL DESIGN
For more information on how we can help with your planning application visuals, please visit our contact page here.
